Linear Way CNC Machine

The TJ-10L Linear Way CNC Machine tool is a best-selling model from Guangdong Taiji for batch processing of medium-sized precision parts. As a high-performance Linear Way CNC Machine tool, it achieves an ideal balance between processing range, speed, and rigidity. Both the X and Y axes utilize high-rigidity precision linear guides, coupled with high-precision C3-grade ball screws. Driven by a high-torque, low-noise, and highly stable AC CNC servo motor, it can provide different speeds for machining various materials. The precision ball screws, along with the high-speed motion and high-load linear guides and couplings, work closely together to ensure stability during machining. The TJ-10L linear guide CNC machine tool is widely used in automotive parts, general machinery, and mold manufacturing.

The TJ-10L Linear Way CNC Machine tool features a specially designed structure: the X and Y axes use linear guides, achieving rapid traverse speeds of up to 24 meters per minute and a cutting feed rate of 12 millimeters per minute, resulting in fast response and feed. The Z axis uses a hardened rail, providing better rigidity and stability during heavy cutting, effectively absorbing cutting vibrations, and extending tool life. This allows it to handle high-speed machining of aluminum alloys as well as difficult-to-machine materials such as mold steel and cast iron, effectively replacing multiple machines and helping to reduce production and processing costs. In terms of travel, the worktable measures 1300×600 mm, with a maximum load capacity of 800 kg, accommodating most medium-sized workpieces. The T-slots range from 5-18×100 mm, allowing for flexible fixture arrangement. The distance from the spindle center to the column guide surface is between 100 and 670 mm, ensuring good accessibility during operation and facilitating tool loading and setting. The feed drive power of the X, Y, and Z axes is 3 kW, ensuring fast response and precise control, achieving both efficiency and accuracy in mass production.

This TJ-10L Linear Way CNC Machine performs exceptionally well in parts processing across multiple industries. In the automotive parts sector, for mass production of components like suspension parts and wheel hubs, its high-rigidity structure combined with a high-efficiency tooling system ensures both efficiency and dimensional stability, meeting the automotive industry's dual requirements of rapid output and long-term reliability.

In general mechanical parts, whether shafts or plates, the TJ-10L offers smooth chip removal and high processing efficiency, making it particularly suitable for production scenarios requiring continuous processing, significantly improving equipment utilization.

All castings on every TJ-10L Linear Way CNC Machine tool are made using Meehanite casting, a high-tensile casting material with strong shock absorption and high wear resistance. Furthermore, they undergo stress relief and aging treatments to ensure the machine maintains optimal precision over extended periods.
