Gantry Type Mill

The TJ-M2016 Gantry Type Mill is an entry-level gantry milling machine specially designed by Guangdong Taiji for heavy-duty machining of large and complex parts. As a high-performance Gantry Type Mill, it adopts a robust gantry frame structure with a 2500×1600mm worktable, easily accommodating large workpieces such as machine beds and engineering machinery components. The gantry machining center series is widely used in civil aviation, automotive, precision mold and parts processing industries, providing reliable mechanical systems and diverse software interfaces to fully realize the dream of high precision.

This TJ-M2016 Gantry Type Mill has undergone solid optimization in five aspects: efficiency, precision, rigidity, multi-functionality, and reliability. First, the rapid traverse speeds of the X/Y/Z axes reach 12, 12, and 10 m/min respectively, significantly shortening cutting and idle travel times. Simultaneously, the optimized feed system results in extremely low vibration during high-speed operation, making it particularly suitable for batch production scenarios, significantly improving equipment utilization and production efficiency. Secondly, it employs high-precision linear guides, precision ball screws, and an advanced servo system. The X/Y axes use heavy-duty roller guides, and the Z-axis uses a high-rigidity rectangular slide rail, maintaining high torque and high precision over long periods, easily handling the stringent tolerances of precision molds and aerospace parts. In terms of rigidity, the X-axis travel is 2100mm, the Y-axis 1600mm, and the Z-axis 700mm (900mm optional). The maximum load capacity of the worktable is 4 tons. The extra-wide column and crossbeam increase the contact area, and combined with the extra-wide base and integrated bed, vibration is minimal during heavy cutting, resulting in excellent stability. Its multi-functional integrated machining capabilities are also outstanding: supporting milling, drilling, boring, tapping, and other composite machining, compatible with steel, cast iron, aluminum, copper, and composite materials. The BT50 spindle taper hole, paired with a 6000rpm spindle (gear head optional), can handle both low-speed heavy cutting and high-speed finishing, completing multiple processes in a single setup, shortening the production cycle. Finally, key components such as guide rails, lead screws, spindles, and control systems are all sourced from top international brands. Each machine undergoes laser calibration, circularity testing, and continuous load trial operation before leaving the factory. Even under high-load continuous processing conditions, the failure rate is very low, and processing performance remains consistently stable. In short, this machine is designed to resolve the contradiction between efficiency and precision in the mass production of large parts, and it deserves your serious consideration.

The TJ-M2016 Gantry Type Mill primarily serves four fields with high requirements for precision and rigidity. In the construction machinery sector, it batch processes heavy parts such as excavator boom connectors, crane slewing bearing seats, and gearbox housings.

It completes multi-face milling and drilling in a single setup, ensuring both dimensional accuracy and processing efficiency, meeting the stringent reliability requirements of the construction machinery industry for components.In the large mold sector, components such as automotive body panel mold inserts, appliance mold cavity plates, and mold frame guide pillars, utilizing a high-rigidity and powerful spindle, achieve efficient material removal and stable precision, significantly shortening the mold manufacturing cycle.

From basic design to ensuring high-speed, high-precision continuous machining, each TJ-M2016 Gantry Type Mill undergoes finite element analysis of its structure. Simulation experiments were conducted on the deformation generated when the machine is under center load to ensure excellent bending rigidity. You don't need to worry about the quality and machining continuity of our machines.

Tools or unprocessed workpieces must not be placed on the gantry machining center or moving objects. Computer desks or workbenches next to the machine must be stable and must not be placed on moving parts. When loading or unloading workpieces, the machine should be stopped first. Maintain an appropriate distance between the workpiece and the tool. Do not open the front door or left and right covers while the machine is running to avoid personal injury. After setting up the tool, please perform a dry run to ensure the program is correct. In the event of a power outage or emergency stop, the three axes should return to their initial mechanical positions. Do not disassemble the limit switches or any components related to safety switches without authorization.

We once helped a factory that mainly produces molds for automotive exterior body panels. Previously, they outsourced roughing and then returned the parts for finishing. This not only resulted in uncontrollable delivery times but also uneven allowances after roughing, leading to frequent tool changes and severe wear during subsequent finishing. After introducing the TJ-M2016 Gantry Type Mill, with its 4-ton worktable load capacity and BT50 spindle heavy cutting capability, the company can directly complete all machining processes from blanks to semi-finished products in-house. The 2200×1400mm worktable can clamp large mold frames at once, improving roughing efficiency by 35%, significantly improving the uniformity of allowance, and reducing subsequent finishing time by 20%. The company has already independently completed over 100 sets of molds, making it the core equipment for its large mold processing. It also undertakes external mold roughing work as an additional source of profit. Therefore, we sincerely invite you to choose the TJ-M2016 Gantry Type Mill and experience its heavy cutting capability for large parts and its superior reliability.
