5-Axis High-Speed Gantry Machining Center

The TJ-MU570 is a 5-Axis High-Speed Gantry Machining Center specifically developed for manufacturers with stringent requirements for precision, efficiency, and rigidity in machining complex, multi-faceted parts. This machine integrates five-axis linkage control technology, enabling milling, drilling, boring, and tapping to be completed in a single setup. It significantly shortens machining cycles, achieves high-precision positioning, and consistently delivers superior part quality. It is primarily suitable for five-axis machining applications such as blades, turbines, complex small precision molds, medical components, and aerospace.

We are equipped with a fully direct-drive five-axis cradle rotary table, helping you achieve backlash-free, zero-wear, and maintenance-free machining, improving accuracy retention. Simultaneously, its extreme positioning accuracy and repeatability enable positioning at any angle, achieving high dynamic response.

The TJ-MU570 5-Axis High-Speed Gantry Machining Center integrates multi-face machining and complex angle machining into a single setup through five-axis synchronous control. This design helps reduce process flow and manual intervention, directly translating your labor costs into higher product yield and more stable machining quality. Standard high-speed, high-precision spindles significantly improve the surface finish and dimensional accuracy of your machined products. The spindle box features a reinforced structural design, simultaneously enhancing cutting capabilities and machining stability. A single unit can cover various materials and multiple machining processes, effectively improving equipment utilization and significantly reducing your overall investment costs. We employ an automatic tool changer system, using a standard 24-position tool magazine (a 30T tool holder multi-tool magazine is optional), with a tool-to-tool time of only 2 seconds, enabling rapid tool changes, improving production efficiency, and saving time costs.

The TJ-MU570 5-Axis High-Speed Gantry Machining Center can perform complex milling, drilling, and tapping machining on steel, aluminum alloys, and other metal materials. In the aerospace field, it is suitable for precision parts such as small impellers and engine casing connectors;

in the energy equipment parts field, it is suitable for precision parts such as small gas turbine blades, turbine disks, and fuel nozzles; in the precision mold parts industry, it is suitable for complex mold parts such as inserts, electrodes, and precision die-casting molds, completing multi-face machining in a single setup, helping you reduce subsequent polishing time;

With five-axis machining, your CNC machine tools can process extremely complex curved contours that are extremely difficult, or even impossible, to machine on simpler machines. Machining all five sides of a part can be completed in a single setup, saving preparation time and reducing clamping and manpower.
Furthermore, five-axis machining improves machining flexibility and accuracy, eliminating the need to move the workpiece between multiple machine tools. This further reduces the need for various fixtures and devices.

We are not just a machine tool manufacturer, but a long-term partner dedicated to helping you improve productivity. With decades of experience in CNC equipment development and a business philosophy of "integrity, quality, service, and win-win cooperation," we have helped a Foshan automotive processing manufacturer improve production efficiency in their wheel hub machining process by flexibly customizing the machine according to specific materials, spindle requirements, and automation configurations. We created an integrated molding production line, significantly reducing time and labor costs.
